30 Ton Forklift

30 ton forklift is a heavy duty diesel forklift with fork positioner, which is widely used in ports, warehouses and logistics transit centers for handling containers and heavy products.

Vicgordan's 30 ton forklift has been designed and manufactured using the latest ergonomic technologies and concepts. This 30 ton forklift has a low cost of ownership, excellent visibility, unmatched productivity, safety and ergonomics for operators in the harshest environments.

  • Features
  • Specifications
  • Picture

Product Details

Engine: WD10G240E21  or cummins engine 6CTA8.3-C260

30 Ton Forklifts Weight:  38,000 kgs

Wheel base: 4400  mm

Rated load: 30,000 kgs

Load center : 1200 mm

Duplex 4m mast

Enclosed cab with A/C

Fork positioner with side shift

Fork length: 2400 mm

Overall Dimension: 9760 * 3360  *4150 mm

30T Diesel Type Heavy Duty Forklift

Mast type: duplex wide view mast

New style steering axle: One piece axle body, new rim installation structure, stronger & more reliable

New style Digital LCD instrument

Hydraulic drive radiator with better cooling performance and low noise, easily to access and daily check

Slide pad type fork shaft, more reliable

New style cabin: better sight, doors on both sides, easier access, better air outlet position of air-conditioner

Move the air filter out of the engine house, easier access

Product Features

Drive Axle

Made in China, Vicgordan-customized, heavy-duty master reducer, pneumatic brake system.


ZhongNan gear-box, multi-stage torque converter, big converter ratio, wide range of auto-adjust speed; stable and smooth shift, 2 stage forward and 1 stage backward, easy operation and maintenance.

Steering System

Vicgordan-made crosswise steering axle; The steering with load sensor and adjustable steering device make the operation easily.

Hydraulic System

Multi-hydraulic valve make it easy to operate. Load sensor hydraulic system, dual pumps supply, dynamic load sensor priority valve, reduce power consumption, lower the hydraulic oil temperature.


The combined chassis structure provide the high intensity and low weight feature, increase the cooling area of the oil tank greatly.

Power System

The customer can choose Cummins turbo 6 cylinder engine or Yuchai engine which according with the GB3 Emission Regulation, high performance, low oil consumption, low speed with high torque, great capacity cooler.

Brake System

Adopt auto parts, air braking system improves the comfort also reduce the pollution cause by oil leakage.

Lifting Assembly

Wide view mast provide great operator visibility; Dual limited speed valves increase the safety; Distance between forks can be adjusted manually is the standard feature, customer can choose fork positioner or sideshifter.

Overhead Guard

Full suspension overhead guard connected the chassis with 4 pivots using the rubber;Tilted structure is easy for maintenance; Smaller column and steering wheel

increase the operator space.

Electrical System

The instrument show all information about the forklift;it will sound alert when low brake pressure or non-lease parking brake.

Every details is well-designed to guarantee the comfortability and safety. It is ergonomically designed. The combined effectiveness of control, monitor, aeration and chair improve the working efficiency for the operator.  All direction has excellent vision.

The right mast can be chosen from our variety of series. 2-stage (with or without free lift) and 3-stages (with free lift) are available

The design of easy-maintenance point, make the inspection and service more convenient and easy.

Centralized control stick is with excellent inching performance, easy to realize millimeter-scale accurate control.

Through advanced FEA, kinematics and dynamics Simulation analysis and calculation, with accurate data support design base, Guarantee the rationality and excellent performance for mast and chassis structure. The overall unit is high reliability and stability.

The overall unit adopts the lightweight design, with excellent fuel consumption savings.

FeaturesRated LoadKg30000
Load Centermm1250
ChassisTire Specs:Front
Tire Specs:Rear
Tires Qty,front/rear(X-drive wheels)
4  2
Wheel tread:Frontmm2430
Wheel tread:Rearmm2230
 DimensionsMast/carriage tilt angle(front/rear)Degree(°)6  12
Mast height(fork lowering)mm4150
Mast lifting heightmm4000
height to head guard(height to cab)mm3460
Overall height(with forks)                                      mm9760
Fork front vertical surface to the rear end of the vehicle                                                                                        mm7360
Overall widthmm3360
Fork dimensionmm2400*320*120
Fork carriage widthmm3000
Mast min ground(with load)mm400
Wheelbase center min ground(with load)mm460
Min.turning Radiusmm6900
Travel speed(with load/without load)km/h25/28
PerformanceMax.lifting speed(with load/without load)mm/s260/280
Grade ability(with load/without load)%20/20
Driving brake
Hydraulic clamp disc
emission IIWP10G240E341 9.726L178kW2200r/min
emission IIIQSC8.3-C260 8.3L194kW2200r/min
emission II6CTA8.3-C260  8.3L194kW2200r/min
Rated Output178(Kw)
Cylinder No6
otherTransmission gears(Front/rear)
2   1
